Feature:
1. MAIN PURPOSE: This sensor is an component for detection, control and contactless switch, with NPN normally open output, with 2mm action distance.
2. GOOD PROTECTION: Has power supply reverse connection protection, short circuit protection and non contact detection device, to ensure high accuracy.
3. WORKING PRINCIPLE: When the sensing surface of the object proximity switch reaches the operating distance, it does not need mechanical contact and apply any pressure.
4. APPLICABLE SCENES: Can be used in automatic control system, for limit, counting, positioning control and automatic protection, etc., suitable for machine tools, etc.
5. LED INDICATOR: When the proximity switch approaches the target object, it sends out a control signal, and the red LED indicates the working status of the sensor.
Specification:
Item Type: Proximity Sensor
Material: ABS
Product Voltage: 6-36VDC
Maximum Output Current: 300mA
Action Distance: 2mm
Repetitive Positioning Accuracy: 0.02mm
Working Frequency: 150Hz
Output: NPN Normally Open
Working Temperature: -25℃-75℃
Protection Grade: IP65
Withstand Voltage: 1500V Per MIN
Package List:
5 x Proximity Sensors
